TopEngineer developed steel detailing (shop and erection drawings) for the needs of liquefied natural gas (LNG) plants. Documentation was developed for Technip company. The uniqueness of this project for our company was as follows: 1. As initial data, we were provided with a rod model with calculated sections and forces for joints. We, in turn, made the calculation of all connection for metal structures. 2.The design often changed in the project due to updated tasks from technologists. We tracked changes and adjusted drawings for steel fabricators or site workers.

Detailing of steel structures is a specialized process for issuing documentation for the manufacture of steel structures at the factory and their installation at site. Often, public buildings have complex architecture, so steel structures are indispensable. This project of the lecture building was developed by the TopEngineer team in 6 months.

TopEngineer developed the shop and erection documentation for Steam reformer furnaces. These furnaces are designed to produce hydrogen at manufacture of chemicals such as TDI, MDI, ammonia and methanol. The project was very difficult, but we successfully completed it. The project included two mirror furnaces.

A stadium is a building with a lot of people. Almost always, the roof of stadiums is made of large-span steel structures. For these designs, you need to carefully resemble the production and detailing of steel structures. All welds must be calculated and marked on detail drawings. For this project, in addition to detailing drawings, we calculated and drew installation schemes for large-span truss.
